Generac Power Systems 0K8420-A User Manual

Installation Drawings
52 Installation Guidelines for Spark-Ignited Stationary Emergency Generators
0K8624-A 22/27 kW (2.4 L) Page 2 of 2
100
[3.9]
51
[2.0]
9
[.4]
104.5
[4.11]
674
[26.5]
STUB-UP
AREA
45 [1.8] TYP 1380 [54.3] TYP
MOUNTING SLOT CENTERS
1580 [62.2]
735 [28.9]
27 [1.0]
TYP
723 [28.5] TYP
MOUNTING SLOT CENTERS
776 [30.6]
96 [3.8]
1370 [54.0] 210 [8.3]
STUB-UP
AREA
28
[1.1]
DIMENSIONS: MM [INCH]
TOP VIEW
LEFT SIDE VIEW
REAR VIEW
CIRCUIT BREAKER
NEUTRAL AND CUSTOMER
CONNECTION OPENING
HIGH AND LOW
VOLTAGE
STUB-UP AREA
13.5 X 29.5
MOUNTING SLOTS
4X
REMOVABLE
STUB-UP COVER

Generac Power Systems 0K8420-A Specifications

General

Brand	Generac Power Systems
Model	0K8420-A
Category	Portable Generator
Language	English
