Generac Power Systems 0K8420-A User Manual

Installation Drawings
56 Installation Guidelines for Spark-Ignited Stationary Emergency Generators
0K9268-A 32/38 kW (2.4 L) Page 2 of 2
786
[30.9]
STUB-UP
AREA
162 [6.4]
162 [6.4]
9 [.4]
51 [2.0]
1733 [68.2]
838 [33.0] TYP
MOUNTING CENTERS
50
TYP
[2.0]
1750 [68.9] TYP
MOUNTING SLOTS
1950 [76.8]
850 [33.5]
888 [35.0]
25
[1.0]
TYP
116
[4.6]
12 [.5]
217 [8.5]
STUB-UP
AREA
CIRCUIT BREAKER
NEUTRAL AND CUSTOMER
CONNECTION OPENING
HIGH AND LOW VOLTAGE
STUB-UP AREA
13.5 X 29.5
MOUNTING SLOTS
4X
TOP VIEW
LEFT SIDE VIEW
REMOVABLE STUB-UP ACCESS COVER
(SHIPPED LOOSE WITH GENERATOR)
TO BE INSTALLED DURING GENERATOR
INSTALLATION
REAR VIEW
DIMENSIONS: MM [INCH]
