Generac Power Systems 0K8420-A User Manual

Installation Drawings
58 Installation Guidelines for Spark-Ignited Stationary Emergency Generators
0L2090-A 60 kW (2.4 L) Page 2 of 2
1733 [68.2] 217 [8.5]
STUB-UP
AREA
12 [.5]
162 [6.4]
9
[.4]
162
[6.4]
51
[2.0]
786
[30.9]
STUB-UP
AREA
1950 [76.8]
50
[2.0]
TYP
1750 [68.9] TYP
MOUNTING SLOT CENTERS
25 [1.0]
TYP
838 [33.0] TYP
MOUNTING SLOT CENTERS
888 [35.0]
116
[4.6]
850 [33.5]
LEFT SIDE VIEW
13.5 X 29.5
MOUNTING SLOTS
4X
HIGH AND LOW
VOLTAGE
STUB-UP AREA
CIRCUIT BREAKER
NEUTRAL AND CUSTOMER
CONNECTION OPENING
TOP VIEW
REMOVABLE
STUB-UP COVER
REAR VIEW
DIMENSIONS: MM [INCH]
