Generac Power Systems Power Zone Pro Sync User Manual

8 Owner’s Manual for Power Zone Pro Sync
General Information
Internal Control Relay Boards
Power Supply 12/24 V
Contact Type SPDT Normally Open (N.O.) or Normally Closed (N.C.)
Relay Ratings
N.O.: 50 Amps at 14 V , 20 Amps at 28 V
N.C.: 30 Amps at 14 V , 15 Amps at 28 V
Customer Relay Board
Power Supply 12/24 V
Contact Type SPDT Normally Open (N.O.) or Normally Closed (N.C.)
Relay Ratings 10 Amps at 250 V / 30 V
Run Relay (Optional)
Power Supply 12/24 V
Contact Type DPDT Normally Open (N.O) or Normally Closed (N.C.)
Relay Rating
N.O.: 10 Amps at 250 V /30 V
N.C.: 5 Amps at 250 V /30 V
Horn
Tone Nature Medium Loud Continuous Tone
Sound Output 93 dB at 61 cm
Resonant Frequency 2.9 ± 0.25 KHz
Keyswitch
Ratings 3-position (AUTO/OFF/MANUAL)
Removable Position All 3 positions (option available to only allow removal in AUTO position)
Emergency Stop
Ratings 2-position push-in and pull-out or twist to release
Fuses (DC and AC)
Ratings
5 Amp , 10 Amp , 15 Amp, 20 Amp , 25 Amp depending on application.
Voltage sense fuses are located inside circuit breaker box.
Communication Interfaces
Ratings See Owner’s Manual for the individual module
Analog/Digital Inputs/Outputs
Ratings See Owner’s Manual for the individual module
NOTE: The communications cables should not be run in the same conduit or in the same wire grouping as any high
voltage or high current conductors.

Generac Power Systems Power Zone Pro Sync Specifications

General

Brand	Generac Power Systems
Model	Power Zone Pro Sync
Category	Controller
Language	English
