Generac Power Systems Power Zone Pro Sync User Manual

Owner’s Manual for Power Zone Pro Sync 7
General Information
Specifications
Environmental Specifications
Operating Temperature -40 °F (-40 °C) to 140 °F (60 °C)
Humidity 0% to 95% Non-Condensing
Enclosure UL Type 1
Weight 62 lbs (if all components are installed)
Power Supply Requirements (DC)
Power Supply Source Battery
Power Supply Voltage 6 V to 35 V (12/24 V Nominal)
Power Supply Power 31 Watts maximum
Power Supply Cable 2 wires - voltage drop across each conductor must be less than 1 V
Power Supply Requirements (AC)
Power Supply Source Emergency Power (utility)
Power Supply Voltage 120/240 V
Power Supply Power 700 Watts maximum
Power Supply Cable 2 wires - voltage drop across each conductor must be less than 1 V
12/24 V, 10 A Analog Battery Charger
Nominal Input AC Line Voltage 120 V
Operating AC Line Voltage
Range
108 V to 132 V
Input AC Line Frequency 50 or 60 Hz
AC Line Fuse 5 Amp, 5x20 mm, Littelfuse
®
(part no. 218005)
Battery Fuse 15 A, Littelfuse ATO Blade (part no. 257015)
Nominal Charge Rate 10 A
Equalize Voltage (typ.) 13.8/27.6 V
Float Voltage (typ.) 13.0/26.0 V
Current at Equalize to Float Tran-
sition (typ.)
5 A
Battery Under Voltage Shutdown
(typ.)
11/22 V
LED Indicators
AC Line Voltage > 108 V
Green LED ON
Battery Connected and
Charging
Yellow LED ON
NOTE: The Green LED must be ON to obtain a valid battery charging indication. Yellow LED is ON if charge
current > approximately 2 amps.
Battery Current Drain (AC Power
OFF)
30 mA (typical)
AC Line Connections via terminal block (AC Hot, AC Neut, and GND)
Battery Connections via terminal block (Pos (+), Neg (-))
Control Connections AC Power Fail Relay, Form C, 2 A, 12/24 V
NOTE: Normally Open (N.O.) Contact closes when AC line voltage is applied. N.O. Contact opens when AC line
voltage is removed.
