60 Owner’s Manual for Power Zone Pro Sync
Troubleshooting
AI Channel DOFs
The following AI Channel DOFs follow the same
principles. To set up alarms for each channel listed
below, refer to the Owner’s Manual for the Power Zone
Main Controller or Power Zone Display.
• Fault 1 – indicates that a fault has occurred at the
first alarm set point for this channel.
• Fault 2 – indicates that a fault has occurred at the
second alarm set point for this channel.
• Fault 3 – indicates that a fault has occurred at the
third alarm set point for this channel.
• Fault 4 – indicates that a fault has occurred at the
fourth alarm set point for this channel.
• Sensor Fault – indicates that there is an issue with
the actual physical sensor on this channel.
• Event – indicates the threshold to trigger an event
has been reached on this channel. This will not
generate a fault, but it allows the user to capture an
occurrence in the event log.
NOTE: “xx” can be number 1-80.
DI Channel DOFs
All following DI Channel DOFs follow the same
principals, In order to setup alarms for each channel
listed below, refer to the Owner’s Manual for the Power
Zone Main Controller/ Power Zone Display.
• Fault – Indicates a fault has occurred on this
channel.
• Event – indicates the threshold to trigger an event
has been reached on this channel. This will not
generate a fault, but it allows the user to capture an
occurrence in the event log.
NOTE: “xx” can be number 1-80.
FC DOF AI CHANNEL xx FAULT 1
FC DOF AI CHANNEL xx FAULT 2
FC DOF AI CHANNEL xx FAULT 3
FC DOF AI CHANNEL xx FAULT 4
FC DOF AI CHANNEL xx SENSOR FAULT
FC DOF AI CHANNEL xx EVENT
FC DOF DI CHANNEL xx FAULT
FC DOF DI CHANNEL xx EVENT
