44 Owner’s Manual for Power Zone Pro Sync
Troubleshooting
J1939 VARISTEP
FAULT
The Varistep governor is
reporting a fault. This could be
due to a time out, low power, over
temperature, over current, a step
error, or other general error.
Each alarm condition can
be set by each Varistep
module. The following bits
will determine which alarm
was reported in the alarm
log message:
• 0x0001 or 0x0002:
Time Out
• 0x0004 or 0x0008: Low
Power
• 0x0010 or 0x0020:
Over Temperature
• 0x0040 or 0x0080:
Over Current
• 0x0800 or 0x0400:
General Error
• 0x8000: Step Error
The alarm clears when
the condition that set the
alarm is no longer
active.
J1939 VARISTEP
LOW VOLTAGE
FAULT
The voltage supplied to the
Varistep governor is too low.
The Varistep has enough voltage
to run, but not enough voltage to
control the motor.
The alarm becomes active
once the Varistep detects
its power supply is too low
to operate for a period of
time. If the generator is
running, the period of time
is one second. If the
generator is cranking, the
period of time is two
seconds.
The alarm is cleared
once the supplied
voltage to the Varistep
rises above the low
voltage limit.
J1939 MIC3
IGNITION FAULT
The MIC3+ Ignition module is
reporting a fault. This could be
due to an operational error,
system error, open, short, engine
stop, or locked firing.
Each alarm condition can
be set by each MIC3+
Ignition module. The
following bits will determine
which alarm was reported
in the alarm log message:
• 0x01: Operational Error
• 0x02: System Error
• 0x04: Primary Open
• 0x05: Primary Short
• 0x06: Secondary Open
• 0x07: Secondary Short
• 0x60: Firing Locked
• 0x70: Waiting for
Engine to Stop
Turn the Keyswitch to
OFF. Verify the MIC3+
faults have been
addressed and cleared.
Clear the shutdown
alarm using the Display.
CAN GOVx
MISSING MODULE
The Power Zone Governor
module #x is not communicating
over CAN bus with the Main
Controller. It is likely missing, not
connected, or damaged.
The Power Zone Governor
sends a message over
CAN bus periodically every
200 milliseconds to the
Main Controller. If after 600
milliseconds the Main
Controller has not received
a message from the
module, the shutdown
alarm is activated.
Turn the Keyswitch to
OFF. Verify CAN bus
communications
between the Main
Controller and the
Governor. Clear the
shutdown alarm using
the Display.
Alarm Display Text Description Set Alarm Clear Alarm
