Table 3-4. J4 Connector
Pin Name Description
Configured Default
NA = Not Configurable
Wire # (Default)
(BS4) J4-1
GPAI 9 General Purpose Analog
Input. Configurable
Throttle Position #2 (+) 465V
(BS4) J4-2
GPAI 10 General Purpose Analog
Input. Configurable
Inlet Manifold Temperature 754V
(BS4) J4-3
GPAI 11 General Purpose Analog
Input. Configurable
Fuel Level
575V
(BS4) J4-4
GPAI 12 General Purpose Analog
Input. Configurable
Battery Charge Current 803
(BS4) J4-5 Ground Ground for Analog/Digital Throttle Position #1 (-) 766R
(BS4) J4-6 Ground Ground for Analog/Digital Oxygen Sensor (-) 805
(BS4) J4-7 Special Analog Input 1 Analog Input. Configurable Throttle Position #1 (+) 766V
(BS4) J4-8 Special Analog Input 2 Analog Input. Configurable Oxygen Sensor 804
(BS4) J4-9 5 V
Analog Sensor Supply
(BS4) J4-10 5 V
Analog Sensor Supply
(BS4) J4-11 5 V
Analog Sensor Supply
(BS4) J4-12 5 V
Analog Sensor Supply
(BS4) J4-13 Ground Ground for Analog/Digital Throttle Position #2 (-) 465R
(BS4) J4-14 Ground Ground for Analog/Digital Inlet Manifold Temp Sensor 754R
(BS4) J4-15 Ground Ground for Analog/Digital Fuel Level Sensor 575R
(BS4) J4-16 Ground Ground for Analog/Digital
(BS4) J4-17 Ground Ground for Analog/Digital
(BS4) J4-18 Ground Ground for Analog/Digital
(BS4) J4-19 Ground Ground for Analog/Digital
(BS4) J4-20 Ground Ground for Analog/Digital Coolant Temp Sensor #2 (-) 68R2
(BS4) J4-21 5 V
Analog Sensor Supply Oil Pressure #1 Supply 69V1
(BS4) J4-22 5 V
Analog Sensor Supply Oil Pressure #2 Supply 69V2
(BS4) J4-23 5 V
Analog Sensor Supply
(BS4) J4-24 5 V
Analog Sensor Supply
18 Owner’s Manual for Power Zone Pro Main Controller
Installation and Operation
