Owner’s Manual for Generac PWRcell Battery 37
User’s Guide
Battery Settings
Table 6-3. Battery Settings
Setpoint Range Default Description
PLM Channel 1 – 12 1
Channel for REbus communications. All devices in a system
must use the same channel (except REbus Beacon).
MinSoCAbs 0 – 20% 2
Minimum state of charge (SOC) absolute- this is the per-
centage of charge the battery will discharge to while the sys-
tem is islanded.
MaxSoCAbs 10 – 100% 100
Maximum state of charge (SOC) absolute- this is the per-
centage of charge the battery will charge to.
MinSoCRsrv 0 – 90% 30
Minimum state of charge (SOC) reserve- this is the percent-
age of charge the battery will discharge to using Self-Supply
Mode.
MaxSoCRsrv 10 – 100% 100
Maximum state of charge (SOC) reserve- when battery SoC
reaches this value, PV power is diverted from charging the
battery to powering local loads saving battery capacity for
future charging. When excess power might otherwise be
clipped, this extra capacity can be used to absorb peak PV.
DschgCurLim 0 – 35 Amps 35
The battery stack will discharge to the BMU up to this cur-
rent limit continuously before converting onto REbus.
ChgCurLim 0 – 35 Amps 35
The battery stack will charge up to this current limit continu-
ously after power has been converted from REbus.
Sleep Time 1 – 720 Minutes 60
Length of time the battery will sleep for upon reaching its
MinSocAbsl while islanded. Battery will wake up every hour
for four minutes to power search.
PowSrch Time 10 – 900 Seconds 240
Power search setting is the length of time the battery will
wake up from sleeping to search for PV power on REbus for
charging.
Module Vset 40.0 – 55 Volts 46.5
Voltage level the battery will drain its modules to upon initiat-
ing the Vset procedure. See Vset Procedure.
