Wiring Diagrams
Installation Manual for Generac PWRcell Battery 47
PWRcell M5
013477
+
–
REbus 380v DC
REbus Cable Entrance
I/O Switch
Black Start Battery
Top
Back
Front
Module CAT5 COMs Cable
Module 5
Module 4
Module 3
Module 1
Module Spacer
Module 2
Module Jumper
E Stop
(Optional)
LED Status Indicator
