Wiring Diagrams
Installation Manual for Generac PWRcell Battery 45
Section 9: Wiring Diagrams
PWRcell M3
013475
REbus 380v DC
REbus Cable Entrance
I/O Switch
LED Status Indicator
Module CAT5 COMs Cabl
e
Top
Back
Front
Module 3
Module 2
Module 1
Module Spacer
Black Start Battery
E Stop
(Optional)
+
–
