Maintenance
9-46
Dashboard fuse panel
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
MODULE9
MODULE
9
10A
Overhead Console Lamp, AMP, Driver Power Seat
Module, Low DC-DC Converter (AMP), 2ND Seat
LH/RH Module, Passenger Power Seat Module,
Electro Chromic Mirror, 2ND Air Ventilation Seat
LH/RH Control Module, DVRS Unit, 2ND Seat LH/
RH Warmer Control Module, Front A/C Controller,
Smart Phone Wireless Charger, Rear A/C Control
Panel, Data Link Connector, Low DC-DC Converter,
A/V & Navigation Head Unit, Front A/C Control
Module, MTS E-Call Module
INVERTER
INVERTER
30A AC Inverter
TRAILER
30A Not Used
MODULE11
MODULE
11
10A
Head Lamp LH/RH, Multifunction Switch, AC
Inverter, ADAS Unit (Parking), AC Inverter Outlet,
Rear Junction Block (Rear Wiper Relay)
REAR A/C
REAR
A/C
10A Rear A/C Control Panel, Rear Blower Motor
MODULE12
MODULE
12
10A IAU, IBU
A/C4
A/C
4
10A
E/R SUB Junction Block (RLY.2/3/6/10), A/C PM
Sensor, Incar Temperature Sensor, Front A/C
Control Module, Rear A/C Control Panel, Front A/C
Controller
A/BAG IND
IND
10A Instrument Cluster, Overhead Console Lamp
E-SHIFTER2
E-SHIFTER
2
10A Electronic ATM Shift Lever Dial
SPARE(IG2)
SPAER
(IG2)
15A DVRS Unit External Battery
MODULE10
MODULE
10
10A ICU Junction Block (ESU)
MODULE7
MODULE
7
10A
Driver Door Module, IBU, Multifunction Switch,
IAU, Stop Lamp Switch
To Next Page
