Dashboard fuse panel
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
MULTI MEDIA1
1
MULTI
MEDIA
25A
[With ISG] Low DC-DC Converter
[W/O ISG] A/V & Navigation Head Unit
MULTI MEDIA2
2
MULTI
MEDIA
10A
Head-Up Display, Instrument Cluster, Security
Indicator, Front A/C Control Module, Front A/C
Controller, Rain Sensor, Rear Occupant Alert (ROA)
Sensor, Rear A/C Control Panel, Power Tail Gate
Unit, Driver/Passenger Power Outside Mirror, Rear
Door Curtain Module, Driver Power Seat Switch,
Driver Power Seat Module, Driver Lumbar Support
Unit
CLUSTER
CLUSTER
10A Instrument Cluster, Head-Up Display
IBU2
IBU
2
10A IBU
AIR BAG2
2
15A SRS Control Module
PRESAFETY
SEAT BELT3
3
PRESAFETY
SEAT BELT
10A Pre-Active Seat Belt Unit
MODULE8
MODULE
8
10A
Rear Radar LH/RH, ECS Unit, ELSD Control Module,
Dosing Control Module, ADAS Unit (Driving), ADAS
Unit (Parking), Front Console Switch, LKAS Unit
Steering Tilt & Telescopic Unit, Crash Pad Switch
MODULE5
MODULE
5
10A
ICU Junction Block (ESU), DVRS Unit, Crash Pad
Switch, Front Console Switch, A/V & Navigation
Keyboard
E-CALL
E-CALL
10A MTS E-Call Module
MODULE3
MODULE
3
10A
Rear Radar LH/RH, Front Radar LH/RH, Smart
Phone Wireless Charger, Front Console Keyboard,
Steering Tilt & Telescopic Unit, Active Air Flap
Module, Multifunction Switch, Clock Spring
