Engine room fuse panel Engine room fuse panel (Engine room junction block)
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
IG1
IG1
30A IG1 Relay
ECU3
E3
30A Engine Control Realy
IG2
IG2
30A IG2 Relay
ACC
ACC
30A ACC Relay
ECU2
E2
10A ECM
MODULE2
MODULE
2
10A
Smart Cruise Control Radar, Front Radar LH/RH,
4WD ECU, EMC Control Module
MDPS2
1
2
10A MDPS Unit
SPARE
SPARE
10A Not Used
SENSOR3
S3
10A
[G4KR] Oxygen Sensor (Up/Down)
[G6D8] Oxygen Sensor #1~#2
[D6JA] PTC Control Heater, Oil Level Sensor,
Electronic VGT Actuator, Oil Pump Solenoid Valve
SENSOR1
S1
10A
[G4KR] Injector #1~#4, E/R Junction Block (RLY.4)
[G6D8] Injector #1~#6(MPI), E/R Junction Block
(RLY.4)
[D6JA] Rail Pressure Control Valve, E/R Junction
Block (RLY.3/RLY.4)
To Next Page
