Maintenance
9-54
Engine room fuse panel Engine room fuse panel (Engine room junction block)
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
SENSOR4
S4
15A
Cooling Fan Motor, [D6JA] High Pressure Fuel
Pump
WASHER
15A Washer Relay
EWP
EWP
20A Electronic Water Pump
SENSOR5
S5
10A
Electronic Oil Pump, [D4HF] Diesel Fuel Heater,
Glow Unit
IEB4
IEB
4
10A IEB Unit
TCU2
T2
15A P/N Relay, TCM
SENSOR2
S2
10A
[G4KR] E/R Junction Block (RLY.2), Oil Control
Valve (Exhaust), Oil Pump Solenoid Valve, Purge
Control Solenoid Valve, RCV Control Solenoid
Valve, Canister Close Valve
[G6D8] E/R Junction Block (RLY.2), RCV Control
Solenoid Valve #1/#2, Purge Control Solenoid
Valve, Oil Pump Solenoid Valve, Oxygen Sensor
#3/#4, Oil Control Valve #1~#4, Canister Close
Valve
[D6JA] E/R Junction Block (RLY.2), PM (Particulate
Matter) Sensor, Lambda Sensor #1/#2, Stop Lamp
Switch, Electronic Thermostat
IGN COIL
IGN COIL
15A
[G4KR] Ignition Coil #1~#4
[G6D8] Ignition Coil #1~#6
ECU4
S4
20A ECM
