Safety system
3-54
OHI038145OHI038145
Installing a Child Restraint System with a
lap/shoulder belt
To install a Child Restraint System on the
rear seats, do the following:
1. Place the Child Restraint System on a
rear seat and route the lap/shoulder
belt around or through the Child
Restraint System, following the Child
Restraint System manufacturer’s
instructions. Make sure the seat belt
webbing is not twisted.
OHI038146OHI038146
2. Fasten the lap/shoulder belt latch
into the buckle. Listen for the distinct
“click” sound.
Information
Position the release button so that it is easy
to access in case of an emergency.
OHI038183LOHI038183L
3. Remove as much slack from the belt
as possible by pushing down on the
Child Restraint System whilst feeding
the shoulder belt back into the
retractor.
4. Push and pull on the Child Restraint
System to confirm that the seat belt is
holding it firmly in place.
If your Child Restraint System
manufacturer recommends the use of a
top-tether with the lap/shoulder belt, see
page 3-39.
To remove the Child Restraint System,
press the release button on the buckle
and then pull the lap/shoulder belt out of
the Child Restraint System and allow the
seat belt to retract fully.
WARNING
If a child restraint is installed in the
second row centre seat, move the
second row seat far back as possible, to
minimise contact with the front centre
air bag (if equipped with front centre
air bag).
