User Manual
HT Series II Inert Gas Purge
10-1474 Issue 3-6 March 2014 19
Technical Data
Specifications
Purge box
Dimensions (w x d x h)
260 x 300 x 180 mm
Weight
9 kg
Pump bleed pressure
2 ± 0.5 psi
N
2
OK set point
0.9 bar
Purge time
HT-4SII
8 minutes
HT-8SII
30 minutes
HT-12SII
30 minutes
HT-8SII with short chamber
24 minutes
Must run time (all systems)
30 minutes
Storage / transportation environment
Ambient temperature
0°C to 40°C
(-10° permissible during transportation)
Relative humidity
10 to 60% non-condensing
Store upright
Operating environment
Ambient temperature
15°C to 30°C
Relative humidity
10 to 60% non-condensing
Altitude
Seal level to 1600 m
This equipment is designed for use in a
pollutions degree 2 environment (normally only
non-conductive pollution occurs).
Inert gas supply
Inert gas
Argon or nitrogen (dry)
Max pressure
8 bar g (9bar absolute)
Min pressure
3 bar g (4 bar absolute)
Flow rate (nominal)
30 litres / minute @ STP
Hose length
2.5 m
Connector type
3/8” BSP female
Emissions
Inert gas will leak from the evaporator during
operation.
Note: Inert gas pressures, flow rates and purging times are factory preset, having been
determined to provide oxygen levels below the minimum oxygen concentration (MOC) limit
for combustion for the associated evaporation.
Electrical
Voltage (V)
Frequency (Hz)
Peak current (A)
USA
120 ± 10%
60
1.9
Europe
230 ± 10%
50
1
Japan
100 ± 10%
50
2.3
Japan
100 ± 10%
60
2.3
Note: The purge system is powered from the pump control cable and requires no external
connection.
Inert purge gasses
Nitrogen or argon (which must be dry) are suitable for use with the inert gas purge system.
Consult your Genevac distributor for advice before using an alternative inert gas.
