Using the DRG700 Configuration Program
The main window for the GUI uses tabs and buttons to navigate between different screens of the
configuration program.
The tabs are located at the top of the screen and will take you to related functions of the DRG700 that
you can configure. The different tabs are:
• Info displays for system wide information for the DRG
• Status displays information for specific functions of the DRG
• System configures system parameters
• Network configures specific functions
The buttons are located at the bottom right hand side of the screen and allow you to save, discard or
review any modifications to the default parameters. The buttons are:
• Apply Changes
• Clear Changes
• Review Changes
• Save Changes (depending on context)
Remember to always Save and then Apply the changes, or they won't be activated!
