B-1
Printer and Paper Specifications
B
Printer and Paper Specifications
This appendix provides the physical, functional, and performance specifications for the
printer. It also contains detailed paper specifications.
Physical Specifications
Dimensions LA36N LA36W
Height: 133 mm (5.2 in) 130 mm (5.1 in)
Width: 434 mm (17 in) 570 mm (22.4 in)
Depth: 330 mm (13 in) 330 mm (13 in)
Weight LA36N LA36W
7.5 kg (16.5 lb) 8.5 kg (18.7 lb)
AC power requirements LA36N/W Low Voltage LA36N/W High Voltage
100 to 120 VAC ±10% 220 to 240 VAC –10%, +6%
50/60 Hz 50/60 Hz
Power consumption Average 120 VA
Maximum 240 VA
Heat generation Average 65 kcal/h
Interface (dual) IEEE 1284 (bidirectional) parallel and DEC-423 serial
Data buffer size 2K, 8K, 16K, 32K or 64K bytes
Operating environment 5 to 38ºC (41 to 100ºF)
30% to 80% RH (no condensation)
Wetbulb temperature, less than 29ºC (84ºF)
Storage environment –15 to 60ºC (–4 to 140ºF)
10% to 95% RH (no condensation)
Acoustic noise Less than 54 dBA (ISO 7779)
