Using Set-Up Mode
baud rate as that used by your computer or modem.
600 BPS
1200 BPS
2400 BPS
4800 BPS
9600 BPS
19200 BPS
<BIT&PARITY> Setting of data format for DEC-423
Number of data bits Parity bit
7 EVEN 7 Even
7 ODD 7 Odd
7 SPACE 7 Space *
7 MARK 7 Mark *
8 EVEN 8 Even
8 ODD 8 Odd
8 NONE 8 None
* The mark is logical 1. The space is logical 0.
<BUFFER CTL>
Setting of data transmission buffer control for DEC-
423
DTR The Data Terminal Ready signal is used.
XON/XOF The DC1 and DC3 codes are used.
<DISC FAULT> Specify the disconnect control of the interface when a
fault condition occurs.
NO DTR is kept as it was.
DROP DTR DTR is turned low and fixed.
PULSE DTR DTR is turned low for five seconds and returned to
the original state.
(Buffer Control)
(Disconnect on
Fault)
