Page #89 background imageLoading...
Page #89 background image
May 2018 Service Manual
Platform Components
Part No. 1275811GT GR
• QS
R • QS
W 75
9-1
Platform
How to Remove the Platform
Perform this procedure with the platform extension
fully retracted and locked in position.
1 Raise the platform to approximately 1 ft / 30
cm.
2 Place support blocks between the platform
and the drive chassis. Lower the platform onto
the blocks.
Crushing hazard. Keep hands
clear when lowering the
platform.
3 Turn the key switch to the off position and
disconnect the battery pack from the machine.
Electrocution/burn hazard.
Contact with electrically charged
circuits could result in death or
serious injury. Remove all rings,
watches and other jewelry.
4 Disconnect the platform controls from the
control cable at the platform. Remove the
platform controls from the platform and set the
controls to the side.
5 Carefully cut the cable ties securing the
control cable to the platform.
Component damage hazard.
The control cable can be
damaged if cut while removing
the cable ties.
6 Remove the fasteners securing the junction
box bracket to the mast. Set the bracket and
fasteners to the side.
7 Attach a lifting strap of suitable capacity from
an overhead crane and center it around the
platform railing. Support the platform. Do not
apply any lifting pressure.
8 Remove the fasteners securing the platform
mount to the mast and set the fasteners to the
side. Remove the platform and mount from the
machine.
Crushing hazard. The platform
will fall if not properly supported.
