Genie GR-12 Service Manual

May 2018
Table of Contents
Part No. 1275811GT GR
™
• QS
™
R • QS
™
W vii
Introduction Introduction ........................................................................................................... ii
Important Information ............................................................................................. ii
Find a Manual for this Model .................................................................................. ii
Revision History..................................................................................................... iii
Section 1 Safety Rules .......................................................................................................... v
General Safety Rules ............................................................................................. v
Section 2 Specifications ....................................................................................................... 1
Machine Specifications ........................................................................................... 1
Performance Specifications .................................................................................... 2
Hydraulic Component and Manifold Specifications ................................................ 3
Hydraulic Oil Specifications .................................................................................... 4
Hydraulic Hose and Fitting Torque Specifications ................................................. 7
Torque Procedure .................................................................................................. 8

Genie GR-12 Specifications

General

Machine Width	1.2 m
Machine Length	2.44 m
Machine Height	2.54 m
Power Source	Electric
Stowed Height	2.54 m
Drive Speed - Lowered	4.8 km/h
Turning Radius (Inside)	2.44 m
Platform Width	1.12 m
Tire Type	Non-marking
Travel Speed	4.8 km/h
Ground Clearance	0.1 m
Overall Length	2.44 m
Overall Width	1.2 m
Overall Height	2.54 m
