Genie GR-12 Service Manual

Service Manual May 2018
Specifications
2 GR
™
• QS
™
R • QS
™
W Part No. 1275811GT
Performance Specifications
Drive speed, maximum
Platform stowed, fast
2.5 mph
40 ft / 10.9 sec
4 km/h
12.2 m /
10.9 sec
Platform stowed, slow
1.1 mph
40 ft / 24.8 sec
1.8 km/h
12.2 m / 24.8 sec
Platform raised
0.5 mph
40 ft / 55 sec
0.8 km/h
12.2 m / 55 sec
Braking distance, maximum
High range on paved surface
19 in ± 6 in
61 cm ± 30 cm
Gradeability
See
Operator's Manual
Function speed, maximum from platform controls
(with 1 person in platform)
GR
-12, QS-12R, QS-12W
Platform up (fast mode)
Platform up (slow mode)
Platform down
19 to 21 seconds
30 to 32 seconds
17 to 19 seconds
GR
-15, QS-15R, QS-15W
Platform up (fast mode)
Platform up (slow mode)
Platform down
20 to 22 seconds
31 to 33 seconds
18 to 20 seconds
GR
-20, QS-20R, QS-20W
Platform up (fast mode)
Platform up (slow mode)
Platform down
23 to 25 seconds
32 to 34 seconds
20 to 22 seconds
Rated work load at full height, maximum
GR
-12, GR-15
(standard platform)
500 lbs
227
kg
GR
-12, GR-15, GR-20
(AWP platform)
350 lbs
159 kg
GR
-20
(standard platform)
350 lbs
159 kg
QS
-12R, QS-15R, QS-12W, QS-15W
stockpicker platform)
500 lbs
227 kg
QS
-20R, QS-20W
(stockpicker platform)
350 lbs
159 kg
For operational specifications, refer to the
Operator's Manual.

Genie GR-12 Specifications

General

Machine Width	1.2 m
Machine Length	2.44 m
Machine Height	2.54 m
Power Source	Electric
Stowed Height	2.54 m
Drive Speed - Lowered	4.8 km/h
Turning Radius (Inside)	2.44 m
Platform Width	1.12 m
Tire Type	Non-marking
Travel Speed	4.8 km/h
Ground Clearance	0.1 m
Overall Length	2.44 m
Overall Width	1.2 m
Overall Height	2.54 m
