Genie GR-12 Service Manual

May 2018 Service Manual
Diagnostics
Part No. 1275811GT GR
™
• QS
™
R • QS
™
W 105
Type "PXXX" Faults
DTC
Number
Message on
GCON LCD
Description Possible Causes Failure Mode
P001:
P001:PWR FAULT
SW PWR1:BAT-
Short circuit of the switched power #1
circuit to battery negative.
• Short circuit in switched power #1, down limit
switch, pothole limit switch, digital tilt switch
harness.
• GCON ECM.
All functions
inhibited.
P003:
P003:PWR FAULT
SW PWR1:BAT+
Short circuit of the switched power #1
circuit to battery positive.
• Short circuit in switched power #1, down limit
switch, pothole limit switch, digital tilt switch
harness.
• GCON ECM.
All functions
inhibited.
P004:
P004:DEVICEFAULT
HORN:BAT-
Short circuit of the automotive horn circuit to
battery negative.
• Short circuit in automotive horn harness.
• Automotive horn short circuit.
• GCON ECM.
Automotive horn
inhibited.
P005:
P005:DEVICEFAULT
HORN:OPEN
Open circuit of the automotive horn circuit.
• Open circuit in automotive horn harness.
• Automotive horn open circuit.
• GCON ECM.
Automotive horn
inhibited.
P006:
P006:DEVICEFAULT
HORN:BAT+
Short circuit of the automotive horn circuit to
battery positive.
• Short circuit in automotive horn harness.
• Automotive horn short circuit.
• GCON ECM.
Automotive horn
inhibited.
P007:
P007:DEVICEFAULT
GCON ALARM:BAT-
Short circuit of the GCON alarm circuit to
battery negative.
• Short circuit in GCON alarm harness.
• GCON alarm short circuit.
• GCON ECM.
GCON alram
inhibited.
P009:
P009:DEVICEFAULT
GCON ALARM:BAT+
Short circuit of the GCON alarm circuit to
battery positive.
• Short circuit in GCON alarm harness.
• GCON alarm short circuit.
• GCON ECM.
GCON alram
inhibited.
P013:
P013:PWR FAULT
PCON PWRET:BAT-
Short circuit of the PCON power return circuit
to battery negative.
• Short circuit in PCON power return harness.
• GCON ECM.
All functions
inhibited.
P015:
P015:PWR FAULT
PCON PWRET:BAT+
Short circuit of the PCON power return circuit
to battery positive.
• Short circuit in PCON power return harness.
• GCON ECM.
All functions
inhibited.
P018:
018:PWR FAULT
PCON POWER:BAT-
Short circuit of the PCON power circuit to
battery negative.
• Short circuit in PCON power harness.
• GCON ECM.
All functions
inhibited.
P019:
018:PWR FAULT
PCON POWER:BAT+
Short circuit of the PCON power circuit to
battery positive.
• Short circuit in PCON power harness.
• GCON ECM.
All functions
inhibited.

Genie GR-12 Specifications

General

Machine Width	1.2 m
Machine Length	2.44 m
Machine Height	2.54 m
Power Source	Electric
Stowed Height	2.54 m
Drive Speed - Lowered	4.8 km/h
Turning Radius (Inside)	2.44 m
Platform Width	1.12 m
Tire Type	Non-marking
Travel Speed	4.8 km/h
Ground Clearance	0.1 m
Overall Length	2.44 m
Overall Width	1.2 m
Overall Height	2.54 m
