Genie GR-12 Service Manual

May 2018 Service Manual
Specifications
Part No. 1275811GT GR
™
• QS
™
R • QS
™
W 1
Section 2 Speci fic ations
Machine Specifications
Batteries, Standard
Voltage
6V DC
Group
GC2
Type
T-
105
Quantity
4
Battery capacity, maximum
C20 = 225AH
Reserve capacity @ 25A rate
447 minutes
Weight, each
62
lbs
28
kg
Batteries, Maintenance-free (option)
Voltage
6V
DC
Group
GC2
Type
6V-
AGM
Quantity
4
Battery capacity, maximum
C20 = 200AH
Reserve capacity @
25A rate
380 minutes
Weight, each
62
lbs
28
kg
DC Motor
Voltage
24V
Horsepower
4.5 HP @ 2950 rpm
Kilowatts
3.3 kW @ 2950 rpm
Fluid capacities
Hydraulic tank
3.75 gallons
14.2 liters
Hydraulic system (including tank)
5 gallons
19 liters
Height, stowed maximum
GR
-12, GR-15, QS-12R, QS-15R,
QS
-12W and QS15W
(ANSI / CSA models)
62 in
1.57 m
GR
-12, GR-15, QS-12R, QS-15R,
QS
-12W and QS15W
(AS / CE models)
68.1 in
1.73 m
GR
-20, QS-20R, QS-20W
78 in
1.98 m
Tires and wheels
Tire size (solid rubber)
10 x 3 in
25.4 x 7.62 cm
Tire contact area
6.5 sq in
41.9 cm
2
Castle nut torque, lubricated
150 ft-
lbs
203 Nm

Genie GR-12 Specifications

General

Machine Width	1.2 m
Machine Length	2.44 m
Machine Height	2.54 m
Power Source	Electric
Stowed Height	2.54 m
Drive Speed - Lowered	4.8 km/h
Turning Radius (Inside)	2.44 m
Platform Width	1.12 m
Tire Type	Non-marking
Travel Speed	4.8 km/h
Ground Clearance	0.1 m
Overall Length	2.44 m
Overall Width	1.2 m
Overall Height	2.54 m
