May 2018 Service Manual
Specifications
Part No. 1275811GT GR
• QS
R • QS
W 3
Hydraulic Component
Specifications
Function pump
Type
Gear
Displacement per revolution
0.244 cu in
4 cc
Flow rate @ 2500 psi / 172 bar
4 gpm
15 L/min
Hydraulic tank return filter
10 micron with
25 psi / 1.7 bar
bypass
Function manifold
System relief valve pressure,
maximum
3500 psi
241 bar
Lift relief valve pressure
1800 to 3500 psi
124 to 241 bar
Steer relief valve pressure
1500 psi
103 bar
Manifold Component
Specifications
Plug torque
SAE No. 2
50 in-
lbs / 6 Nm
SAE No. 4
13 ft-
lbs / 18 Nm
SAE No. 6
18 ft-
lbs / 24 Nm
SAE No. 8
50 ft-
lbs / 68 Nm
SAE No. 10
55 ft-
lbs / 75 Nm
SAE No. 12
75 ft-
lbs / 102 Nm
