May 2018 Service Manual
Diagnostics
Part No. 1275811GT GR
• QS
R • QS
W 109
Battery Charger
The charger continuously monitors internal and external conditions. Fault and Error codes are generated
by the charger to indicate that an internal or external malfunction has been detected in the electrical system.
The types of Diagnostic Trouble Codes that may occur are explained below.
Type "F" codes Indicate an internal fault condition has occurred and caused charging to stop.
Type "E" codes - Indicate an external fault condition has occurred and caused charging to stop.
Type "P" code - Indicates charger programming mode is active. This will occur when the charger profile is
being configured.
Type "USB" code - Indicates the USB interface is active, and the USB should not be removed. This will
occur when the charger firmware is being updated.
Solid red - Internal fault condition. Type "F" fault code.
Flashing amber - External fault condition. Type "E" error code.
Flashing green - USB interface is active.
Solid green - Firmware update is complete. Remove USB from charger.
Codes are displayed as F, E or P and followed by three numbers and a period (example: E-0-0-4). The
charger can display multiple codes.
If the batteries are changed from one type to another, (example: flooded lead acid to AGM), the charger
profile must be programmed. Refer to Repair Procedure, Programming the Charger Profile.
