May 2018 Service Manual
Quarterly Maintenance Procedures
Part No. 1275811GT GR
™
• QS
™
R • QS
™
W 27
8 Turn the key switch to platform controls.
9 Press and hold the high speed lift enable
button.
10 Press the platform up button and raise the
platform approximately 4 feet / .2 m.
11 Press the platform down button and lower the
platform to the stowed position.
Result: The alarm should sound when the
platform is in motion.
12 Press and hold the low speed lift enable
button.
13 Press the platform up button and raise the
platform approximately 4 feet / .2 m.
14 Press the platform down button and lower the
platform to the stowed position.
Result: The alarm should sound when the
platform is in motion.
15 Press and hold the drive/steer function enable
switch on the control handle. Move the control
handle off center, hold for a moment and then
release it. Move the control handle off center
in the opposite direction, hold for a moment
and then release it.
Result: The motion alarm should sound when
the control handle is moved of center in either
direction.
16 Press and hold the drive/steer function enable
switch on the control handle. Press and hold
the thumb rocker switch for a moment to the
left position and then release it. Press and
hold the thumb rocker switch for a moment to
the right position and then release it.
Result: The motion alarm should sound when
the rocker switch is moved off center in either
direction.
Q-8
Inspect the Tires and Wheels
(including castle nut torque)
Genie specifications require that this procedure be
performed quarterly.
Maintaining the tires and wheels, including proper
wheel fastener torque, is essential to safe
operation and good performance. Tire and/or
wheel failure could result in a machine tip-over.
Component damage may also result if problems
are not discovered and repaired in a timely fashion.
1 Check the tire surface and sidewalls for cuts,
cracks, punctures and unusual wear.
2 Check each wheel for damage, bends and
cracked welds.
3 Remove the cotter pin and check the castle
nut for proper torque. Refer to Specifications,
Tire and Wheel Specifications.
Note: Always replace the cotter pin with a new one
when removing the castle nut or when checking the
torque of the castle nut.
4 Install a new cotter pin. Bend the cotter pin to
lock it in place.
