Zoom80 | 148Technical Data
Control unit
Instrument Ports
Display: 1/4 VGA (320 x 240 pixels), colour, graphics
capable LCD, illumination, touch screen
Keyboard: 34 keys
including 12 function keys and 12 alphanu-
meric keys, illumination
Angle Display: 360°’", 360° decimal, 400 gon, 6400 mil,
V%
Distance Display: m, ft int, ft us, ft int inch, ft us inch
Position: In both faces, face two is optional
Touch screen: Toughened film on glass
Port Name Description
Port 1 Port 1 • 5 pin LEMO-0 for power, communication, data
transfer.
• This port is located at the base of the instrument.
Port 2 Handle • Hotshoe connection for ZRT80 with RCS.
Port 3 BT • Bluetooth module for communication.
