Zoom80 | 86Check & Adjust
4.3 Combined Adjustment (l, t, i, c and Aim360)
Description The combined adjustment procedure determines the following instrument
errors in one process:
Combined
adjustment
procedure
step-by-step
The following table explains the most common settings.
l, t Compensator longitudinal and transversal index errors
i Vertical index error, related to the standing axis
c Horizontal collimation error, also called line of sight error
Aim360 Hz Aim360 zero point error for horizontal angle option
Aim360 V Aim360 zero point error for vertical angle option
Step Description
1. Main Menu: Tools...\Check & Adjust...
2. TOOLS Check & Adjust Menu
Select the option: Combined (l,t,i,c,Aim)
3. TOOLS Combined I
<Aim Adjust: On> Includes the determination of the Aim360 Hz
and V adjustment errors.

It is recommended to use a clean GeoMax circular prism as
target. Do not use a 360° prism.
