4.7 Inspecting the Laser Plummet of the Instrument

The laser plummet is integrated into the vertical axis of the instrument. Under
normal conditions of use, the laser plummet does not need adjusting. If an
adjustment is necessary due to external influences, the instrument has to be
returned to a GeoMax service workshop.
Inspecting the
laser plummet
step-by-step
4
5
6
360°
≤ 3 mm / 1.5 m
Ø 2.5 mm / 1.5 m
2
3
1
F12
SHIFT
F6
