Operation Zoom80 | 57
3.4 Fixing the Controller to a Holder and Pole
Components of
the ZHR102
holder
Clamp
a) Ball joint
b) Clamp
c) Tightening screw
Holder
d) Fixation screw
e) Mounting plate
f) Mounting arm
g) Ball joint
h) Tightening screw
i) Double joint clamp
003628_001
a
b
c
d
e
f
g
h
i
