GeoMax Zoom80 Series User Manual

Description of the System Zoom80 | 23
1.4 Components
1.4.1 Instrument
Instrument
components
part 1 of 2
a) Carry handle
b) Optical sight
c) Telescope, integrating EDM, Aim360
d) NavLight flashing diode - yellow and red
e) Scout360, transmitter
f) Scout360, receiver
g) Coaxial optics for angle and distance
measurement, and exit port of visible
laser beam for distance measurements
h) CompactFlash card compartment
i) Horizontal drive
j) Tribrach securing screw
abcdefg
hi j
Zoom80_002a
