Check & Adjust Zoom80 | 91
4.4 Tilting Axis Adjustment (a)
Description This adjustment procedure determines the following instrument error:
Determination of
tilting axis error
step-by-step
The following table explains the most common settings.
a Tilting axis error
Step Description

The Hz collimation error (c) has to be determined before starting this
procedure.
1. Main Menu: Tools...\Check & Adjust...
2. TOOLS Check & Adjust Menu
Select the option: Tilting Axis (a)
