Zoom80 | 58Operation
Attaching the
controller to the
holder
step-by-step
Step Description
1. Remove holder from the travel container.
2. Insert the pole into the clamp hole.
3. Tighten the clamp with the tightening screw.
4. Adjust the angle and height of the mounting plate and holder on the
pole to comfort.
5. Tighten holder with the tightening screw.
Once tightened, the tightening screw can be slightly loosened to
change the position of the handle for more comfort.
A locking mechanism is incorporated in the mounting plate of the
holder.
6. Before the controller is placed onto the mounting plate ensure that
the locking pin is put into the unlocked position. To unlock the locking
pin, push down the red button situated on top of the mounting plate.
