Zoom80 | 156Technical Data
Measurements can be made to reflector tapes over the entire range without
external ancillary optics.
Accuracy Accuracy refers to measurements to standard prisms.
Beam interruptions, severe heat shimmer and moving objects within the beam
path can result in deviations of the specified accuracy.
The display resolution is 0.1 mm.
Characteristics
EDM
measuring
mode
std. dev.
ISO 17123-4,
standard prism
std. dev.
ISO 17123-4,
tape
Measurement
time, typical [s]
Standard 1mm + 1.5ppm 5mm + 2ppm 2.4
Fast 3mm + 1.5ppm 5mm + 2ppm 0.8
Tracking 3mm + 1.5ppm 5mm + 2ppm < 0.15
Principle: Phase measurement
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: System analyser basis 100 MHz - 150 MHz
