Zoom80 | 158Technical Data
Accuracy
Object in shade, sky overcast. Beam interruptions, severe heat shimmer and
moving objects within the beam path can result in deviations of the specified
accuracy. The display resolution is 0.1 mm.
Characteristics
Laser dot size
Standard measuring std. dev.
ISO 17123-4
Measure time,
typical [s]
Measure time,
maximum [s]
0m - 500m 2mm + 2ppm 3 - 6 12
>500 m 4 mm + 2 ppm 3 - 6 12
Type: Coaxial, visible red laser
Carrier wave: 658 nm
Measuring system: System analyser basis 100 MHz - 150 MHz
Distance [m] Laser dot size, approximately [mm]
at 30 7 x 10
at 50 8 x 20
