Zoom80 | 36User Interface
Screen area The working area of the screen.
Message line Messages are shown for 10 s.
Icons Shows current status information of the instrument. Refer
to "2.4 Icons". Can be used with touch screen.
ESC
Can be used with touch screen. Same functionality as the
fixed key ESC. The last operation will be undone.
CAPS The caps mode for upper case letters is active.The caps
mode is activated and deactivated by pressing
UPPER(F5) or LOWER(F5) in some screens.
SHIFT icon Shows the status of the SHIFT key; either first or second
level of softkeys is selected. Can be used with touch screen
and has the same functionality as the fixed key SHIFT.
Quick coding icon Shows the quick coding configuration. Can be used with
touch screen to turn quick coding on and off.
Softkeys Commands can be executed using (F1)-(F6) keys. The
commands assigned to the softkeys are screen-
dependent. Can be used directly with touch screen.
Scroll bar Scrolls the screen area up and down.
Element Description
