Comander Perimeter Security System
Engineering and Installation Manual
Page 68 of 72
6.2.1.1 Collator Board LED Indicators
Each Collator board has an LED indicator showing the status of each circuit. The
LEDs are arranged to correspond with the ribbon-cable connections from the lightning
protection boards, so the top row of LEDs displays the status of the inputs connected to
the top ribbon-cable.
The LEDs indicate status as follows:
• Off: Secure
• On Continuous: Alarm
• Flashing: Tamper
