Get Packed GPAS-158 - Page 75

75
FIGURE 17-1 FEEDING UNIT
NO
PART NUMBER
Description
QTY
1
P02-033670B
FEED SEAT
1
2
P02-033810A
FEED BANDWAY
1
3
P02-0337900
TENSION DRIVING ROLLER
1
4
P01-0558200
FEED SPACER PLATE
1
5
P02-0337700
GUIDE BLOCK LEFT
1
6
P02-0337800
GUIDE BLOCK RIGHT
1
7
P02-035100A
FEED BANDWAY COVER
1
8
P1104-026002ZZ3
BEARING
1
9
P0319-S15838
BRAKE
1
11
P1104-026202ZZ2
BEARING
1
12
P0701-0004800
TENSION GEAR
1
13
P1108-010505010G
KEY 5*5*10
1
14
P0319-S15832
LIMIT SWITCH
1
15
P01-055910A
GUIDE COVER
1
16
P1101-0904008AN
SCREW M4*8
6
17
P1103-01062102Z
WASHER M6x21x2t
1
18
P1103-0206Z
SPRING WASHER φ6
2
19
P1101-0506012AN
SCREW M6*12L
1
20
P1103-0204Z
SPRING WASHER φ4
4
21
P1101-0504016AN
SCREW M4*16L
4
22
TENSION UNIT – FIG 19-1
1
23
P02-0337400
TENSION ARM SHAFT
1
24
P01-055850B
BANDWAY ADJUST PLATE
1
25
P1101-0905012AN
SCREW M5*12
5
26
P02-0336800
TENSION CAM SHAFT
1
27
P1104-0308120
DRY BUSHING
2
28
P06-0065400
SPACER
1
29
P1103-011521B2C
WASHER ψ15*21*0.2
1
30
FEED DRIVEN UNIT – FIG 18-1
1
