FIGURE 17-1 FEEDING UNIT
NO
PART NUMBER
Description
QTY
31
P1104-020635ZZ2
BEARING
1
32
P02-0336900
TENSION CAM LEVEL
1
33
P1101-0504020AN
SCREW M4*20
1
34
P1103-0204Z
SPRING WASHER φ4
1
35
P1102-0104AN
NUT M4
1
36
P1103-0205Z
SPRING WASHER φ5
2
37
P1103-010510N
WASHER φ5
2
38
P1101-0505040AN
SCREW M5*40
2
39
P01-0559200
FAN BRACKET
1
40
P01-055880B
ADJUSTMENT FIXING PLATE
1
41
P1103-010612N
WASHER φ6*12*1t
2
42
P1103-0206Z
SPRING WASHER φ6
1
43
P1102-0106BZ
NUT M6
2
44
P1105-0108B
C -RING S-8
1
45
P1109-0205022G
PIN 5*21.8MM
1
46
P0319-S158412
FAN AC230V
1
P0319-S158411
FAN AC110V
1
47
P02-0338500
FEED FORCE ADJUSTING ROD
1
48
P1102-0106AN
NUT M6
2
49
P1103-0208Z
SPRING WASHER φ8
3
50
P02-0337500
TENSION SPRING CAP
1
51
P1102-0108AZ
NUT M8
2
52
P02-0105400
TENSION ADJUST NUT
1
53
P1201-0004700
SPRING
1
54
P1104-060001600
ROD END
1
55
P1104-060001500
ROD END
1
56
P02-0337600
TENSION ADJUST LEVER
1
57
P1101-0508030AN
SCREW M8*30
1
58
P1103-010816N
WASHER φ8*16
1
