FIGURE 23-1 SEPARATING PLATE UNIT
NO
PART NUMBER
Description
QTY
1
P02-033410A
SEPARATOR
1
2
P01-0556700
SEPARTOR GUIDE PLATE
1
3
P02-033420B
ACTUATOR FIXER
1
4
P01-055660B
ACTUATOR
1
5
P1101-0203006AZ
SCREW M3x6
2
6
P01-0642500
DETECTOR PLATE
1
7
P1101-0303006AZ
SCREW M3x6
2
8
P1103-01030801Z
WASHER φ3
2
9
P01-0042800
BUSHING
1
10
P1101-0604006AN
SCREW M4X6
4
11
P01-058770C
SEPERATOR PLATE FIXER LFFT
1
12
P01-058780A
SEPERATOR PLATE FIXER RIGHT
1
13
P1202-0013100
PROX. DETECTOR SPRING
1
14
P0319-S15833
PROXIMITY SWITCH
1
15
P01-0631500
PROXIMITY PLATE FIXER
1
16
P01-0642600
PROXIMITY PLATE
1
17
P1101-0904008AN
SCREW M4*8
2
