Advanced Menu
The Advanced menu contains the advanced settings as shown next.
Japanese Keyboard:
SATA Mode
Total Graphics Memory:
Serial port COM1:
Serial port COM2:
Serial port COM3:
Serial port COM4:
Boot-time Diagnostic Screen:
Wake-On-LAN(WOL)
Turbo Mode
Intel Trusted Execution
Intel AMT Setup Prompt:
[Disabled]
[AHCI]
[MaxDVMT]
[Enabled]
[Enabled]
[Enabled]
[Enabled]
[Disabled]
[Disabled]
[Enabled]
[Disabled]
[Enabled]
F1 Help ↑↓ Select Item -/+ Change Values F9 Setup Defaults
Esc Exit ←→ Select Menu Enter Select Sub-Menu F10 Save and Exit
Japanese Keyboard enables support for the Japanese keyboard.
SATA Mode sets the mode to enhanced
AHCI
(Advanced Host Controller
Interface) or
IDE
. Turbo memory feature works only when the SATA AHCI
mode is enabled.
Total Graphics Memory sets the amount of total graphics memory
(pre-allocated + fixed + DVMT) for use by the internal graphics device.
Serial Port COM1/COM2/COM3/COM4 allows you to unconditionally disable
it when set at
Disabled
.
Boot-time Diagnostic Screen allows you to display the diagnostic screen
during system boot-up.
Wake-On-LAN (WOL) allow a LAN activity to wake up the system from S3
(Sleep) state.
Turbo Mode sets if turbo memory is enabled.
