9
Ref
Component Description
When pressed longer:
Serves as the Ctrl+Alt+Del keyboard keys.
NOTE: The hardware buttons (except the power button) can be re-defined using
G-Manager.
Rear Components
To access a connector, open its protective cover by lifting up the tab of the
cover. When closing the cover, push the tab downward until the cover clicks
into place.
Ref
Component Description
Power
connector
Connects the AC adapter.
HDMI connector Connects a HDMI monitor or TV set.
USB
3.1 Gen
2
port
Connects a USB device.
RJ-45 connector Connects the LAN cable.
Serial port Connects a serial device.
Kensington lock
Locks the computer to a stationary object for
security.
