Repair and adjustment
9
Service instructions
5015108-00Edition 0403
6. Change the jumper (X29) on the board for the PACS 300 control system from Normal to Test.
Flash
Prom
X28
X29
TEST
Norma
X30
ON OFF
V1544
7. Set up as shown.
File name Choose the right program file (*.a37).
Com Port The port to which you connected the data cable to your PC.
Baudrate Choose 57600
All Sectors and Verbose must be checked (=selected).
V1578
