Repair and adjustment
29
Service instructions
5015108-00Edition 0403
Adjusting DOOR UP safety switch
This may only be done by authorised personnel.
The DOOR UP safety switch is fitted only to machines with automatic door.
To prevent damage, the spring must be adjusted so that the door stops when a
force of 150 N is applied to the door when the door is moving up. The illustration
below shows how to adjust the spring.
V1435
Safety switch
DOOR DOWN
