Getinge 8668 - Adjusting the Door Closing Force

Repair and adjustment
32
Service instructions
5015108-00 Edition 0403
V1583
Closed position
Adjusting the door closing force
This must only be done by authorised personnel.
When door is in its top position, the motor pulls the door in from the outer to the inner position.
The force with which it does this is adjusted with a spring as shown below.
Note:
The spring must never fully compressed.
22.5 + 1 mm
