Getinge Maquet Orchide User Manual

9
Technical specifications
Electrical specifications of cameras and receivers
40 / 44
Maquet Orchide
IFU 04661 EN 02
VP01 RECEIVER technical specifications
Specifications VP01 RECEIVER
Video input RJ45 (proprietary)
Video output 3G-SDI
Weight (without/with mounting bracket) 230 g / 260 g
Dimensions with mounting bracket (L x W x H) 143 × 93 × 32 mm
Tab.15: VP01 RECEIVER technical specifications
AIR03/04 SYSTEM E/U technical specifications
Specifications AIR03/04 SYSTEM E/U
Video output HDMI 1.4
Weight (without/with mounting bracket) 220 g / 340 g
Dimensions with mounting bracket (L x W x H) 156 × 117 × 61 mm
Transmission frequencies see below
Tab.16: AIR03/04 SYSTEM E/U technical specifications
AIR03 SYSTEM E/U transmission frequencies:
UE zone: Central frequency of transmission channels in accordance with ETSIEN301893:
5.190GHz and 5.230GHz
USA zone: Central frequency of transmission channels in accordance with the FCC15.407
standard: 5.190GHz, 5.230GHz, 5.755GHz and 5.795GHz
AIR04 SYSTEM E/U transmission frequencies:
UE/US zone: Central frequency of transmission channels in accordance with the
ETSIEN301893 and FCC Sec.15.407 standards: 5.190GHz, 5.230GHz, 5.270GHz,
5.310GHz, 5.510GHz, 5.550GHz and 5.670GHz
Electromagnetic compatibility of the device
Device Description Supplier
Wireless HDMI video transmission system EXT-WHD-1080P-SR GEFEN**
VE819 ATEN**
NOTICE
The technical specifications of the AIR03 and AIR04 wireless systems are de-
scribed in the documentation available on the GEFEN and ATEN websites.
