Introduction
Information about this document
6 / 44
Maquet Orchide
IFU 04661 EN 02
Prerequisites:
• The sterilisable handle must be compatible with the product.
1. Fit the handle to the mount.
Ø A click is heard.
2. Turn the handle until it locks into place with a second click.
1.2.2.4 Menus and buttons
Menu and button names are shown in bold.
Example:
1. Press the Save button.
Ø The changes are saved and the Favourites menu is displayed.
1.2.3 Definitions
1.2.3.1 Hazard levels
The text in safety instructions describes types of risk and how to avoid them. Safety instructions
are classified into the following three levels:
Symbol Hazard level Meaning
DANGER! Indicates a direct and immediate risk that may be
fatal or cause very serious injuries potentially lead-
ing to death.
WARNING! Indicates a potential risk that may cause injuries,
health hazards or serious material damage leading
to injuries.
CAUTION! Indicates a potential risk that may cause material
damage.
Tab.1: Hazard levels of safety instructions
1.2.3.2 Indications
Symbol Indication type Meaning
NOTICE Additional assistance or useful information not relat-
ing to risks of injuries or risks of material damage.
ENVIRONMENT Information relating to recycling or to appropriate
disposal of waste.
Tab.2: Types of indication in the document
