Getinge Maquet Orchide User Manual

9
Technical specifications
EMC declaration
42 / 44
Maquet Orchide
IFU 04661 EN 02
Type of test Test methods Range of fre-
quencies
Boundaries
Measurement of the radiated
electromagnetic field
EN 55011 GR1 CL
A
3
30 - 230MHz 40 dBµV/m PQ 10m
230 - 1000MHz 47 dBµV/m PQ 10m
Tab.17: EMC declaration
Type of test Test methods Test level: Healthcare facil-
ity.
Electrostatic discharge im-
munity
EN 61000-4-2 Contact: ± 8kV
Air: ± 2; 4; 8; 15kV
Immunity to radiated electro-
magnetic fields
EN 61000-4-3 80 MHz, 2.7 GHz
3V/m Mod AM 80%/1kHz
Wireless RF frequencies
9 to 28V/m Mod AM
80%/1kHz
Immunity to fast electrical tran-
sients and bursts
EN 61000-4-4 AC: ± 2kV - 100kHz
IO >3m: ± 1kV - 100kHz
Immunity to power source
voltage surges
EN 61000-4-5 ± 0.5; 1 kV diff.
± 0.5 kV, ± 1 kV, ± 2 kV com-
mon mode
Immunity to conducted inter-
ference due to electromagnetic
fields
EN 61000-4-6 150 kHz, 80 MHz
3Vrms Mod AM 80%/1kHz
ISM
6Vrms Mod AM 80%/1kHz
Immunity to voltage dips and
short interruptions
EN 61000-4-11 0% Ut, 10ms
(0°; 45°; 90°; 135°; 180°; 225°;
270°; 315°)
0% Ut, 20ms
70% Ut, 500ms
0% Ut, 5s
Tab.18: EMC declaration
